  1. Guide to Copper Alloy 122: Properties and Applications

    Leave a Comment

    Copper tubes on white background

    The addition of phosphorus to copper alloy 122 makes it an excellent option for heavy-forming processes. In fact, this material is easier to braze and weld than 110 copper, even if they are almost identical mechanically. Also, copper alloy 122 has great resistance to corrosion caused by water, weather, and soil. This makes it an outstanding material for underground and plumbing applications. Copper alloy 122 is also used in various household and industrial applications. Read on to learn more.

    What Are the Properties of Copper Alloy 122?

    Copper alloy 122 is preferred in various sectors due to its valuable properties. We can break them down into two components as follows:

    Chemical Composition

    The chemical composition of copper alloy 122 contains two elements, copper (Cu) at a minimum of 99.9% and phosphorus (P), which can range from 0.015% to 0.040%. Note that the copper value also includes silver (Ag). The chemical composition of copper alloy 122 makes it a good candidate for diverse applications in several sectors.

    Mechanical Information

    The mechanical composition of copper alloy 122 can be broken down into various elements, which are highlighted below. Copper alloy 122 has a density of 0.323 lb./in., an ultimate tensile strength of 49,300 psi, and yield tensile strength of 45,000 psi. Also, it has a shear modulus of 6,380 ksi and a modulus of elasticity of about 17,400 ksi. The melting point of copper alloy 122 varies from 1,880° F to 1,980° F.

    Other Common Names for Copper Alloy 122

    While copper alloy 122 is the correct terminology used in most sectors, there are other names that people use to refer to the same product. Some of the common trade names of copper alloy 122 include:

    • UNS C12200
    • CDA 122
    • DHP Copper
    • DHP Phosphorized
    • High Residual P
    • Phosphorus-Deoxidized Copper
    • C122

    Applications of Copper Alloy 122

    Due to its high heat transfer qualities, its corrosion-resistance properties, and a smooth interior, it is used as tubing for drinking water since it doesn’t restrict flow. Industries that want to make high, medium, and low-pressure copper tubes use copper alloy 122.

    Generally, you’ll find copper alloy 122 in both households and industrial settings. This material is applied as shown below:

    Household:

    • Plumbing tubes
    • Air conditioners
    • Oil burner tubes
    • Heat liners
    • Refrigerators
    • Gas lines

    Industrial:

    • Evaporator tubes
    • Brewery tubes
    • Heat exchanger tubes
    • Distiller tubes
    • Gasoline
    • Oil lines
    • Water lines
    • Dairy tubes
    • Hydraulic lines
    • Steam lines
    • Condensers

    Copper Alloy 122 Products at Interstate Metal

    If you are in either of these sectors that rely heavily on copper alloy 122, you’ll want to get these products from a good company that produces high-quality materials of this product. Interstate Metal is a very reliable place where you can find copper alloy 122 products for use in general settings or any other environments that you deem necessary.

    Interstate Metal has an extensive array of copper 122 products. At the moment, you can select from the following products:

    Source Copper Alloy 122 Products from Interstate Metal

    The valuable qualities of copper alloy 122 make it one of the most sought-after materials in multiple industries, such as hydraulics, breweries, and water and oil sectors. Since copper alloy 122 is deoxidized with phosphorus, you can also use it in several heavy-forming procedures.

    If you are looking for copper alloy 122 products, Interstate Metal is your one-stop shop. We are the leading experts in manufacturing and distributing copper, aluminum, lead, and brass alloys. When you need our products, we are always happy to provide your preferred shapes or sizes of any alloys that suit your needs. Our mill can manufacture custom orders, and our warehouse is well stocked for immediate shipping or pickup. Also, our team is always ready to assist with any technical assistance you may need. Contact us for more details about copper alloy 122 or request a quote from Interstate Metal today.

  2. C110 Copper Alloy Guide: Properties and Applications

    Leave a Comment


    Copper 110, often referred to as C110, is a copper alloy that has been specifically formulated to have superior electrical and thermal conductivity. The ideal application for this metal would be in any type of equipment where electricity must flow from one point to another, such as wiring or electrical components. C110 Copper is also highly formable, meaning it can bend easily without breaking and does not require a lot of force when being formed into a desired shape. Another important aspect of 110 Copper is its corrosion resistance—it will not corrode over time like most other types of metals do when exposed to the elements. This makes C110 an excellent choice for many different indoor and outdoor components.

    Browse Our C110 Copper Bars

    What Are the Properties of C110 Copper?

    Circular and hexagonal copper bars in pileC110 is a form of copper with electrical and thermal conductivity characteristics.

    Chemical Composition

    The material of choice for the new C110 line is pure copper, which has a 99.9% copper content with the other 0.1% being oxygen.

    C110 is a highly conductive copper-based alloy with outstanding electrical and thermal conductivity properties, which is superior to other products available on the market. When heated, it is not brittle or embrittlement-prone like other copper alloys, such as copper alloy 122. C110 also contains the same amount of oxygen that occurs naturally in pure copper (Cu). This makes the alloy ductile, which is beneficial for electronic components that must be free from hazardous impurities and oxide films.

    C110 has excellent electrical conductivity, outstanding thermal conductivity, freedom from hydrogen embrittlement, and the potential for cold-working.

    Mechanical Information

    C110 Copper H02 (Half Hard) Temper

    • Ultimate Tensile Strength: 42,100 psi
    • Yield Strength: 36,300 psi
    • Rockwell Hardness: B40
    • Machinability: 20% 1/2″ or 3/4″ brass rod, also known as free-cutting brass rod (C360)
    • Melting Point: 1,950-1,980° F

    Other Common Names for C110 Copper Alloy

    Electrolytic Tough Pitch (ETP) copper is another name for copper alloys with a high carbon content, such as C110. They are also more technically referred to as UNS C11000, CDA 110 ETP, C110, and ISO Cu-ETP.

    Applications of C110 Copper Alloy

    C110 is commonly used in industrial applications where there is a need for ductility (such as in plumbing or roofing) or electrical conductivity (for example, electromagnets, bus bars, electrical motors, and other electrical equipment). It’s most often utilized in the home/residential/ architectural realm for its color (such as a kitchen backsplash or cutting board) or heat transfer qualities (e.g., pots and pans).

    In the building and construction industry, C110 Copper has many applications. These typically include: plumbing hardware, wiring, skylight frames, flashing, gutters, and more.

    Copper 110 can be welded with precaution, but generally the sort of inert gases required are not recommended for use with copper.

    C110 Copper Products at Interstate Metal

    Interstate Metal Inc. is a prominent pure copper alloy supplier with a large stock of C110 Copper bars in round, square, and rectangular forms. We have a wide array of ETP C11000, which is used in a variety of applications owing to its excellent electrical and thermal conductivity, corrosion resistance, and ease of fabrication.

    Source C110 Copper Alloy Products From Interstate Metal

    Interstate Metal Inc. is a leading source for brass, copper, aluminum, and lead-free brass alloys in the United States. We know that you want your business to look professional. We offer high-quality products and services at reasonable rates, allowing you to make a profit while saving money on supplies. With our low overhead costs and fair prices, we cater to all types of businesses, from large corporations to startups.

    Why Choose Interstate Metal, Inc.?

    Interstate Metal is a hardware manufacturer that serves North America. We employ only top-notch experts from the fields of engineering, production, administration, sales, and warehousing. The company president has 25 years of mill expertise and 30 years of copper expertise. Additionally, each employee has at least 10 years of experience with our firm.

    Lead-Free Fixtures

    Interstate Metal, Inc. is the first in line when it comes to adhering to California Assembly Bill (AB) 1953, which requires that certain plumbing components be “lead free.” For these purposes, “lead-free” refers to not more than 0.2% lead when applied as solder and flux, and not more than a weighted average of 0.25% when applied as wetted surfaces of pipes, fittings, and fixtures.

    Engineering Department

    All of our engineering department heads and the company president hold bachelor’s degrees in mechanical engineering. With our collective education and experience, we can create your designs from the ground up. For the utmost precision in design, engineering, and manufacturing, we work with the most up-to-date CAD/CAM/CAE software technology.

    Quality Assurance

    Our team of quality assurance professionals ensures that our products meet all necessary criteria. Our metrology lab, which is equipped with the most up-to-date measurement equipment, including CMM, Optical Comparator, Spectrophotometer, and Surface Profiler, among other things, works closely with us to ensure high standards.

    Contact Interstate Metal for Your Next Project

    Interstate Metal is a great choice when you need high-quality C110 copper products to begin your next project. Our helpful staff is eager to assist you with all of your requirements for copper as well as other high-quality metal products. To learn more about our C110 products, contact our team today.
